Chain hoist winch chain hoist 1T / 3m

Manufacturer number: Steinberg Systems 10030375

The chain hoist from the German brand Steinberg Systems is a versatile device that will be perfect for various manufacturing companies, mechanical engineering plants, warehouses or construction sites. Its primary use is lifting and lowering heavy objects.

The manual chain hoist allows lifting objects weighing up to 1000 kg to a height of up to three meters. Thanks to durable chains (type G80, links with a diameter of 6 mm) and the manufacture of high-quality steel components, work with the SBS-FZ 1000/3M model is very safe. This is also influenced by the nylon-covered end of the control rod and the safety mechanism, which stops the operation of the equipment when the chain is released.

To increase the user's convenience, the hoist is equipped with two rotating hooks and a lever with a light ratio connected to a mechanism inside the housing. It enables the user to lift and lower the object comfortably.

Product features:

• - Efficiency - maximum lifting capacity of up to 1,000 kg allows lifting objects to a height of 3 m,
• - Convenience - control lever and safety mechanism that stops the operation of the equipment when the chain is released,
• - Safety - steel construction, high quality workmanship, two rotating hooks and lever with non-slip handle.

• - Model - SBS-FZ 1000/3M
• - Part number - 10030375
• - Article condition - New
• - Maximum load capacity - 1000 kg
• - Material - Steel
• - Maximum lifting height - 3 m
• - Minimum distance between hooks - 265 mm
• - Required force to lift the weight - 340 N
• - Chain type - G80
• - Number of load chains - 1
• - Chain link diameter - 6 mm
• - Dimensions (DxSxW) - 23.5 x 14.5 x 13 cm
• - Weight - 9 kg
• - Shipping dimensions (DxSxW) - 24 x 19.5 x 18.5 cm
• - Shipping weight - 9.4 kg

Included:

• Chain winch
• Instruction manual EN
